Basic Electrical Circuits: Series and Parallel

Series vs parallel circuits and Ohm's law — the foundation of electrical trade and engineering studies.

Electricity needs a loop

A circuit is a complete path for electric current: energy source → conductor (wires) → load (lamp, resistor) → back to the source.

Series circuits

One path only. The same current flows through every component. Voltages add up: Vtotal = V₁ + V₂. Remove one lamp — the whole circuit goes dark (old-style Christmas lights!).

Parallel circuits

Multiple branches. Each branch gets the full supply voltage; currents add up. Remove one lamp — the rest keep working. That's why your house is wired in parallel.

Ohm's law

V = I × R — voltage (volts) = current (amperes) × resistance (ohms). Also I = V/R and R = V/I.

Worked example

A 12 V battery drives a 4 Ω resistor: I = V/R = 12/4 = 3 A.

Safety first

Never work on a live circuit; use insulated tools; treat every circuit as live until tested dead. On TVET courses: always follow your workshop's safety procedure.

Practise

  1. Find I if V = 230 V and R = 46 Ω.
  2. Two 6 Ω resistors in series — total resistance?
  3. Why are homes wired in parallel?

Watch the video to see both circuit types in action.
